Kyocera ECOSYS M3560idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-3-99
7. Select [On] using the cursor right/left keys.
8. Press the start key. Starts reading or writing.
The progress of selected item is displayed in %.
When an error occurs, the operation is canceled and an error code is displayed.
9. When normally completed, [Fin] is displayed.
10. Turn the main power switch off and on after completing writing when selecting [Import].
Error Codes
Codes Description
e000
Unspecified error
e0001
Parameter error
e0002
Failed to generate a Dummy file
e0003
The target XML file to import does not exist
e0004
The exported file does not exist
e0100 to e01ff
Error in handling the addressbook
e0200 to e02ff
Error in handling One-touch
e0300 to e03ff
Error in handling user management
e0400 to e04ff
Error in handling panel-program data
e0500 to e05ff
Error in handling forwarding Fax data
e0600 to e06ff
Error in handling system configurations
e0700 to e07ff
Error in handling network parameters
e0800 to e08ff
Error in handling job accounting
e0900 to e09ff
Error in handling short-cuts
e0a00 to e0aff
Error in handling job information
e0b00 to e0bff
Error in handling Fax data
e0c00 toe0cff
Error in handling printer data
e0d00 to e0dff
Error in handling panel data
e0e00 to e0eff
Error in handling document boxes
e1000 to e1fff
Error in handling device-related information
e2000 to e2fff
Error in handling SOAP IF
e3000 to e3fff
Error in handling KM-WSDL IF
e4000 to e4fff
A file mandatory for importing is missing (e4002)/Invalid file header (e4008)
e5000 to e5fff
Error in handling rewriting SOAP data
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.

Kyocera ECOSYS M3560idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	275000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	23.1 dB
Sound pressure level (copying)	54.3 dB
Sound pressure level (quiet mode)	49.8 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	71 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	803 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	590 mm
