Kyocera ECOSYS M3560idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-4-108
(3) Scan to E-mail error codes
Code Contents Check procedures/corrective measures
1101 SMTP/POP3 server does not exist on
the network.
1. Check the SMTP/POP3 server name.
2. Confirm device's network parameters.
3. Confirm the network parameters the device is con-
nected.
1102 Login to the SMTP/POP3 server has
failed.
1. Confirm user name and password.
2. Check the SMTP/POP3 server.
1104 The domain the destined address
belongs is prohibited by scanning
restriction.
1. Confirm device's SMTP parameters.
1105 SMTP protocol is not enabled. 1. Confirm device's SMTP protocols.
1106 Sender’s address is not specified. 1. Confirm device's SMTP protocols.
2101 Connection to the SMTP/POP3 server
has failed.
1. Check the SMTP/POP3 server name.
2. Confirm that the LAN cable is properly connected to
the device.
3. Check the SMTP/POP3 port number.
4. Confirm device's network parameters.
5. Confirm the network parameters the device is con-
nected.
6. Check the SMTP/POP3 server.
2102 Connection to the SMTP/POP3 server
has failed.
(Connection timeout)
1. Check the SMTP/POP3 server name.
2. Check the SMTP/POP3 port number.
3. Confirm device's network parameters.
4. Confirm the network parameters the device is con-
nected.
5. Check the SMTP/POP3 server.
2103 The server cannot establish communi-
cation.
1. Check the SMTP/POP3 server name.
2. Check the SMTP/POP3 port number.
3. Confirm device's network parameters.
4. Confirm the network parameters the device is con-
nected.
5. Check the SMTP/POP3 server.
2201 Connection to the SMTP/POP3 server
has failed.
1. Confirm device's network parameters.
2. Confirm the network parameters the device is con-
nected.
2202 Connection to the SMTP/POP3 server
has failed.
(Timeout)
1. Confirm device's network parameters.
2. Confirm the network parameters the device is con-
nected.
2204 The size of scanning exceeded its limit. 1. Confirm device's network parameters.
1.
3101 SMTP/POP3 server responded with an
error.
1. Confirm device's network parameters.
2. Confirm the network parameters the device is con-
nected.
3. Check the SMTP/POP3 server.
3102 Error: Server Response. 1. Check the SMTP/POP3 server.
2. Wait a minute and trye again.

Kyocera ECOSYS M3560idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	275000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	23.1 dB
Sound pressure level (copying)	54.3 dB
Sound pressure level (quiet mode)	49.8 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	71 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	803 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	590 mm
