Kyocera ECOSYS M5521cdw

To Next Page

To Previous Page

10-34

Troubleshooting > Clearing Paper Jams

Remove any jammed paper in Cassette 2

Open Rear Cover 2.

Remove any jammed paper.

Push Rear Cover 2.

CAUTION

• Do not reuse jammed papers.

• If the paper tears during removal, be sure to remove any loose scraps of paper from inside the machine.

Scraps of paper left in the machine could cause subsequent jamming.
