Kyocera ECOSYS P2040dw Service Manual

2RT/2RV/2RW/2RX/2RY/3RA
7-94
F24X Abnormality detecting in the system Manage-
ment Department
(1) Check contact of a DDR memory and perform an operation
check.
(2) Exchange a Main/Engine PWB and perform an operation check.
(3) Get USBLOG and contact service headquarters.
* F248 is the abnormalities of a printer
process.In recurring by specific printer
data, please give me cooperation at
acquisition of capture data and
USBLOG.
[Controller failure]
Cleared by turning power off and
on onlyUSB log is required for
investigation
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
[Controller failure]
Cleared by turning power off and
on onlyUSB log is required for
investigation
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
F25X Abnormality detecting in a network manage-
ment department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and packet capture and contact service head-
quarters.
* It may occur according to a visitor's
network environment.
[Main unit<=>Outside network]
Ethernet connector
[Main unit<=>Outside network]
Ethernet connector
F26X,
F27X,
F28X,
F29X,
F2AX
Abnormality detecting in the system Manage-
ment Department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
(SSM:F26X)
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
(SSM:F26X)
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
F2BX,
F2CX,
F2DX,
F2EX,
F2FX,
F30X,
F31X,
F32X
Abnormality detecting in a network control part (1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.(Depending on
an analysis result, it is packet capture acquisition)
[Main unit<=>Outside network]
Ethernet connector
[Main unit<=>Outside network]
Ethernet connector
F35X Abnormality detecting in the printing controlling
Management Department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
[Main/Engine PWB<=>Video
device]
Main/Engine PWB: YC1, YC2,
YC3, YC5, YC6, YC7, YC9, YC10,
YC14, YC21, YC23
[Main/Engine PWB<=>Video
device]
Main/Engine PWB: YC1, YC2,
YC3, YC5, YC6, YC7, YC9, YC10,
YC14, YC21, YC23
F38X Abnormality detecting in the authentication
authorized Management Department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
[Main unit<=>Authentication
device]
USB Host connector
[Main/Engine PWB<=>USB con-
nector]
Main/Engine PWB: YC510
[Main unit<=>Authentication
device]
USB Host connector
[Main/Engine PWB<=>USB con-
nector]
Main/Engine PWB: YC510
F3AX,
F3BX,
F3CX,
F3DX,
F3EX,
F3FX,
F40X,
F41X,
F42X,
F43X,
F44X,
F45X
Abnormality detecting in the Entity Manage-
ment Department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Num-
ber
Contents Verification procedure & check point Remarks LCD model LED model

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
