Kyocera ECOSYS P2040dw Service Manual

2RT/2RV/2RW/2RX/2RY/3RA
7-95
F46X Abnormality detecting of a printer rendering part (1) Exchange boards and perform an operation check.
(2) the acquisition wish of USBLOG -- carry out
(Depending on the (2) case, it is print capture data acquisition)
* F46F is the abnormalities of a printer
process.In recurring by specific printer
data, please give me cooperation at
acquisition of capture data and
USBLOG.
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
F47X Abnormality detecting of an image editing pro-
cessing part
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
(F47X)
Not Support(F48X)
Not Support(F49X)
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
(F47X)
Not Support(F48X)
Not Support(F49X)
[Main/Engine PWB]There are no
hardware components that can be
checked in the field
F4DX,
F4EX
Abnormality detecting in the Entity Manage-
ment Department
(1 Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Support(F4DX)
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
Support(F4DX)
[Main/Engine PWB]
There are no hardware parts that
can be checked in the field
F4FX Abnormality detecting in the JOB Management
Department
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
F51X,
F52X,
F53X,
F55X,
F56X,
F57X
Abnormality detecting in a JOB execution part (1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
F5FX Abnormality detecting in a service execution
part
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Since the USB log immediately after
occurrence is needed for analysis,
please give me cooperation of acquisi-
tion.
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
F62X Abnormality detecting in a service execution
part
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Since the USB log at the time of occur-
rence is needed for analysis, please
give me cooperation of acquisition.
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
F63X Abnormality detecting in a device control sec-
tion
(1) Exchange a Main/Engine PWB and perform an operation check.
(2) Get USBLOG and contact service headquarters.
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Support
[Main/Engine PWB]
There are no hardware compo-
nents that can be checked in the
field
Num-
ber
Contents Verification procedure & check point Remarks LCD model LED model

Kyocera ECOSYS P2040dw Specifications

General

Processor family	ARM Cortex
Built-in processor	Yes
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Sound pressure level (quiet mode)	45.5 dB
Color	No
Print technology	Laser
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	2000 - 3000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
Display	LCD
Certification	TÜV-GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	802.1x RADIUS, HTTPS, IPPS, IPSEC, SNMP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
