Kyocera ECOSYS P3055dn Service Manual

2T6/2T7/2T8/2T9
2-3-3
YC7 13 OPEN - - NC
Connected to
the eKUIO
14 GND - - Ground
15 OPEN - - NC
16 OPEN - - NC
17 GND - - Ground
18 DP I/O Analog USB data signal
19 DN I/O Analog USB data signal
20 VBUS O DC0V/3.3V 3.3 V DC power output to eKUIO
YC9 P1 TD1+ I/O Analog Send data
Connected to
the Ethernet
P2 TD1- I/O Analog Send data
P3 TD2+ I/O Analog Send data
P4 TD2- I/O Analog Send data
P5 CT1 I 3.3 V DC 3.3 V DC power output
P6 CT2 I 3.3 V DC 3.3 V DC power output
P7 TD3+ I/O Analog Send data
P8 TD3- I/O Analog Send data
P9 TD4+ I/O Analog Send data
P10 TD4- I/O Analog Send data
YC31 1 +3.3V2 O DC3.3V 3.3 V DC power output to OP
Connected to
the
IEEE1284
2 +5.0V2 O DC5.0V 5 V DC power output to OP
3 P1284DIR O DC0V/3.3V Direction input signal
4 NACK O DC0V/3.3V Acknowledge input signal
5 BUSY O DC0V/3.3V Busy input
6 PERROR O DC0V/3.3V Errer signal
7 SELECT O DC0V/3.3V Select signal
8 NFAULT O DC0V/3.3V Errer signal
9 PDATA1 I/O DC0V/3.3V Data signal
10 PDATA2 I/O DC0V/3.3V Data signal
11 PDATA3 I/O DC0V/3.3V Data signal
12 PDATA4 I/O DC0V/3.3V Data signal
13 PDATA5 I/O DC0V/3.3V Data signal
14 PDATA6 I/O DC0V/3.3V Data signal
15 PDATA7 I/O DC0V/3.3V Data signal
16 PDATA8 I/O DC0V/3.3V Data signal
17 NSELECTIN I DC0V/3.3V Select signal
18 NSTROBE I DC0V/3.3V Output signal
19 NAUTOFD I DC0V/3.3V AUTO-FEED signal
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
