Kyocera ECOSYS P3055dn Service Manual

2T6/2T7/2T8/2T9
2-3-8
YC4 1 MMOTCW O 0/5 V DC MM drive shift signal
Connected to
the drum
motor and
main motor
*: 7 to 12 of
the pin num-
ber are used
for 60/50/45
ppm model
only
2 MMOTRDYN I 0/3.3 V DC MM ready signal
3 MMOTCLKN O 0/5 V DC(pulse) MM clock signal
4 MMOTONN O 0/5 V DC MM: On/Off
5 GND - - Ground
6 +24V3 O 24 V DC 24 V DC power output
7 DMOTCW O 0/5 V DC DRM rotation direction
8 DMOTRDYN I 0/3.3 V DC DRM ready signal
9 DMOTCLKN O 0/5 V DC(pulse) DRM clock signal
10 DMOTONN O 0/5 V DC DRM: On/Off
11 GND - - Ground
12 +24V3 O 24 V DC 24 V DC power output
YC5 1 +24V3_IL O 24 V DC 24 V DC power output to DEVCL
Connected to
the duplex
cltch,mid
cltch,
registration
clutch,paper
feed cltch
and
developer
clutch
2 DLPCLN O 0/3.3 V DC DEVCL: On/Off
3 +24V3_IL O 24 V DC 24 V DC power output to PFCL
4 FEEDCLN O 0/24 V DC PFCL: On/Off
5 +24V3_IL O 24 V DC 24 V DC power output to RCL
6 REGCLN O 0/24 V DC RCL: On/Off
7 +24V3_IL O 24 V DC 24 V DC power output to PCCL
8 MIDCLN O 0/24 V DC PCCL: On/Off
9 +24V3_IL O 24 V DC 24 V DC power output to DUCL
10 DUCLN O 0/24 V DC DUCL: On/Off
YC6 1 +24V0 O 24 V DC 24 V DC power output
Connected to
the interlock
switch
2 +24V0_IL O 24 V DC 24 V DC power output
YC7 1 CAS3 I 0/24 V DC CSSW: On/Off
Connected to
the cassette
size switch
2 CAS2 I 0/3.3 V DC CSSW: On/Off
3 CASSET - - CSSW common signal
4 CAS1 I 0/3.3 V DC CSSW: On/Off
YC8 1 +24V3_IL O 24 V DC 24 V DC power output to MPSOL
Connected to
the MP sole-
noid
2 MEFSOLN O 0/24 V DC MPSOL: On/Off
YC10 1 +24V0 O 24 V DC 24 V DC power output to PSFM
Connected to
the power
source fan
motor
2 FANRN O 0/24 V DC PSFM: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera ECOSYS P3055dn Specifications

General

Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Web-based management	Yes
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.6 s
Print speed (black, normal quality, A4/US Letter)	55 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.9 W
Power consumption (ready)	11 W
Power consumption (printing)	675 W
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	54.7 dB
Sound pressure level (quiet mode)	50.4 dB
Display	LED
Certification	TÜV-GS, CE
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
