2T6/2T7/2T8/2T9
2-3-9
YC12 1 +3.3V3_F2 O 3.3 V DC 3.3 V DC power output to EFS
Connected to
the eject full
sensor
2 GND - - Ground
3 PAPFULN I 0/3.3 V DC EFS: On/Off
YC13 1 LIFTMOTOR O 0/5 V DC LM: On/Off
Connected to
the lift motor
*: 60/55/50
ppm model
only
2 GND - - Ground
YC14 1 +3.3V9 O 3.3 V DC 3.3 V DC power output to LS
Connected to
the lift sensor
*: 60/55/50
ppm model
only
2 GND - - Ground
3 LSENS I 0/3.3 V DC LS: On/Off
YC15 1 +24V3_IL_F5 O 24 V DC 24 V DC power output to PM
Connected to
the polygon
motor
2 GND - - Ground
3 PLGDRN O 0/5 V DC PM: On/Off
4 PLGRDYN I 0/3.3 V DC PM ready signal
5 POLCLK O 0/3.3 V DC(pulse) PM clock signal
YC16 1 +5V3_F1 O 5 V DC 5 V DC power output to APCPWB
Connected to
the APC
PWB
2 VDATA1P O LVDS Video data 1 signal (+)
3 VDATA1N O LVDS Video data 1 signal (-)
4 VDATA2P O LVDS Video data 2 signal (+)
5 VDATA2N O LVDS Video data 2 signal (-)
6 SAMPLEN1 O 0/3.3 V DC Sample / hold signal 1
7 SAMPLEN2 O 0/3.3 V DC Sample / hold signal 2
8 OUTPEN O 0/3.3 V DC Laser enable
9 VCONT1 O Analog LD-1 Light volume adjustment
10 VCONT2 O Analog LD-2 Light volume adjustment
11 GND - - Ground
12 PDN I 0/3.3 V DC (pulse) Main scanning synchronizing signal
13 +3.3V3_F2 O 3.3 V DC 3.3 V DC power output to APCPWB
YC18 1 GND - - Ground
Connected to
the power
switch
2 POWERSW I 0/3.3 V DC PSSW: On/Off
Connector Pin Signal I/O Voltage Description
