Kyocera ECOSYS P3060dn Service Manual

2T6/2T7/2T8/2T9
1-4-38
(16)
A paper jam in the
paper feed, paper
conveying or eject
section is indi-
cated when the
main power switch
is turned on.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Regist sensor 2 and Drum PWB (YC6)
DU sensor 1 and Relay-L PWB (YC9)
PF feed sensor and PF main PWB
Eject full sensor and engine PWB (YC12)
Eject sensor and Engine PWB (YC26)
2. A piece of paper torn
from paper is caught
around registration
sensor, duplex sen-
sor, PF feed sensor,
eject full sensor or
eject sensor.
Check visually and remove it, if any.
3. Defective sensor. Replace the registration sensor, duplex sensor, PF feed
sensor, eject full sensor or eject sensor.
4. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-22).
(17)
A message indicat-
ing cover open is
displayed when the
top cover is closed.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Interlock switch and engine PWB (YC6)
2. Defective interlock
switch.
Check and replace if necessary.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-22).
(18)
A message indicat-
ing cover open is
displayed when the
rear cover is
closed.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Rear cover switch and relay-L PWB (YC10)
Relay-L PWB and engine PWB (YC2/YC31)
2. Defective rear cover
switch.
Check and replace if necessary.
3. Defective PWB. Replace the engine PWB or the relay-L PWB and check for
correct operation (see page 1-5-22, 1-5-24).
Problem Causes Check procedures/corrective measures

Kyocera ECOSYS P3060dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.9 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.8 W
Power consumption (ready)	11 W
Power consumption (printing)	684 W
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Display	LED
Certification	TÜV-GS, CE ISO 9001 ISO 14001
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	51.5 dB
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
