Kyocera ECOSYS P3060dn Service Manual

3S3
1-1-4
(4) Envelopes and postcards
When selecting envelopes and postcards, use the guidelines given below.
(4-1) Envelopes
An envelope is a more complex objects than a single sheet of paper. For this reason, it may not be possible to obtain con-
sistent printing quality over the entire envelope surface. Use the following guidelines to select the proper envelopes.
Envelopes should have the basis weight of 70 to 100g/m
2
(0.16 to 0.22 lb./ream) and up to 4 plies of the paper that is
used to construct the paper including all flaps and overlaps.
Envelopes should have sharply-creased folds and accurately joined corner edges.
Envelopes should have a smooth, uncoated surface. Envelopes that are too smooth, however, can give an adverse
effect to the drum and fuser units inside the printer.
Envelopes should have a straight grain orientation.
Envelopes should have a pulp content of al least 80%, and should have a moisture content of 4 to 6%.
Figure below shows some typical envelope types:
This is the type of envelope best recommended
for use with the bulk paper feeder.
Although this type of envelope generally feeds
normally, they are somewhat prone to jamming
than above.
This type of envelope performs reliably, pro-
vided that envelopes are loaded so that the bot-
tom (sealed end) feeds into the printer first.
Avoid using this type of envelope made of dou-
ble-ply paper.
Figure 1-1-1Types of envelopes
Before printing on envelopes of any type, test printing performance. Avoid using any of the following kinds of envelopes
even if the envelope meets the requirements above.
Envelopes that have exposed adhesive surface, or having a peel-off sealing string for adhesive surface. (Peeled-off
sealing string inside the printer can cause a serious problem.)
Envelopes with metal fasteners or tie strings.
Envelopes with transparent windows, holes, perforations, or cutouts.
Envelopes made using paper, pigment, adhesive, or other material that will degenerate or release hazardous gases
when subjected to the heat that is generated in the printer.
Envelopes that is bent, dirty, or redundant of paper dust.

Kyocera ECOSYS P3060dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.9 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.8 W
Power consumption (ready)	11 W
Power consumption (printing)	684 W
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Display	LED
Certification	TÜV-GS, CE ISO 9001 ISO 14001
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	51.5 dB
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
