Kyocera ECOSYS P3060dn - Page 174

2T6/2T7/2T8/2T9
2-3-11
YC20 17 GND - - Ground
Connected to
the main
PWB
18 USBH_DP3 I/O Analog
19 USBH_DN3 I/O Analog
20 GND - - Ground
21 SDIF_DAT0 I/O DC0V/3.3V
22 SDIF_DAT1 I/O DC0V/3.3V
23 SDIF_DAT2 I/O DC0V/3.3V
24 SDIF_DAT3 I/O DC0V/3.3V
25 SDIF_SDCLK I DC0V/3.3V
26 GND - - Ground
27 SH1D I DC0V/3.3V
28 GND - - Ground
29 LDOUT_1_DN I LVDS
30 LDOUT_1_DP I LVDS
31 GND - - Ground
32 GND - - Ground
33 GND - - Ground
34 GND - - Ground
35 GND - - Ground
36 GND - - Ground
37 GND - - Ground
38 GND - - Ground
39 LVU_SLEEP_
N
I DC0V/3.3V
40 POWER_SW O DC0V/3.3V
41 E2C_IRN O DC0V/3.3V
42 E2C_WKUP_
BGD_N
O DC0V/3.3V
43 ENG_HLDN I DC0V/3.3V
44 C2E_QUICK_
START
I DC0V/3.3V
45 PVSYNC O DC0V/3.3V VSYNC
46 GND - - Ground
47 P2C_WKUP_
RDY
O DC0V/3.3V
48 ENERGYSAV
ERKEY_N
O DC0V/3.3V
49 C2P_RST_N I DC0V/3.3V Panel reset signal
50 P2C_SDAT O DC0V/3.3V Panel received data sjgnal
Connector Pin Signal I/O Voltage Description
