Kyocera ECOSYS P3060dn Service Manual

3NY
1-3-3
1030 PF lift motor 2 error
(paper feeder 2)
After cassette 3 is inserted, PF lift
sensor 2 does not turn on within 10
s. This error is detected four times
successively.
Defective bot-
tom plate eleva-
tion mechanism
in the cassette.
Check to see if the bottom plate can
move smoothly and repair it if any prob-
lem is found.
Defective con-
nector cable or
poor contact in
the connector.
Reinsert the connector. Also check for
continuity within the connector cable. If
none, replace the cable.
PF lift motor 2 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of the PF lift
motor.
Check if the gears rotate smoothly. If
not, grease the bushes and gears.
Check for broken gears and replace if
any.
Defective PF lift
motor.
Replace the PF lift motor 2.
Defective PF
main PWB.
Replace the PF main PWB.
(See page 1-4-4)
1040 PF lift motor 3 error
(paper feeder)
After cassette 4 is inserted, PF lift
sensor 3 does not turn on within 10
s. This error is detected four times
successively.
Defective bot-
tom plate eleva-
tion mechanism
in the cassette.
Check to see if the bottom plate can
move smoothly and repair it if any prob-
lem is found.
Defective con-
nector cable or
poor contact in
the connector.
Reinsert the connector. Also check for
continuity within the connector cable. If
none, replace the cable.
PF lift motor 3 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of the PF lift
motor.
Check if the gears rotate smoothly. If
not, grease the bushes and gears.
Check for broken gears and replace if
any.
Defective PF lift
motor.
Replace the PF lift motor 3.
Defective PF
main PWB.
Replace the PF main PWB.
(See page 1-4-4)
Code Contents Causes
Check procedures/
corrective measures

Kyocera ECOSYS P3060dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	4.9 s
Print speed (black, normal quality, A4/US Letter)	60 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter XL24E, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3, XPS
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.8 W
Power consumption (ready)	11 W
Power consumption (printing)	684 W
Wi-Fi	-
Security algorithms	HTTPS, IPPS, IPSEC, SSL/TLS
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Display	LED
Certification	TÜV-GS, CE ISO 9001 ISO 14001
Product color	Black, White
Display number of lines	5 lines
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Noise level (ready)	27.1 dB
Maximum internal memory	2560 MB
Sound pressure level (printing)	56 dB
Sound pressure level (quiet mode)	51.5 dB
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Maximum media length	915 mm
Paper tray media types	Banner, Plain paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Other operating systems supported	Android, iOS
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	416 mm
Width	380 mm
Height	320 mm
