Kyocera FS-1010 User Manual

Expansion Memory Installation
A-5
After removing the side cover, you can see the DIMM socket on top of
the main circuit board.
4
Remove the DIMM from its package.
5
Open the clips on both ends of the DIMM socket.
6
Insert the DIMM into the DIMM socket so that the notches on the
DIMM align with the corresponding protrusions in the slot.
DIMM socket
Clips
DIMM
