Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
1-5-41
Problem Causes Check procedures/corrective measures
(36)
A paper jam in the
paper feed, paper
conveying or fuser
section is indicated
when the power
switch is turned on.
(37)
The message re-
questing covers to
be closed is dis-
played when the
front cover and con-
veying cover are
closed.
(38)
Others.
A piece of paper torn from
print paper is caught
around feed switch 1/2/3,
registration switch,
feedshift switch or eject
switch.
Defective feed switch 1.
Defective feed switch 2.
Defective feed switch 3.
Defective registration
switch.
Defective eject switch.
Defective feedshift switch.
Poor contact in the con-
nector terminals of safety
switch 1 or 2.
Defective safety switch 1
or 2.
Wiring is broken, shorted
or makes poor contact.
Noise.
Check and remove if any.
Run maintenance item U031 and turn feed switch 1 on and off
manually. If "1" is not displayed when the switch is on or "0" is
not displayed when the switch is off, replace feed switch 1.
Run maintenance item U031 and turn feed switch 2 on and off
manually. If "1" is not displayed when the switch is on or "0" is
not displayed when the switch is off, replace feed switch 2.
Run maintenance item U031 and turn feed switch 3 on and off
manually. If "1" is not displayed when the switch is on or "0" is
not displayed when the switch is off, replace feed switch 3.
Run maintenance item U031 and turn the registration switch on
and off manually. If "1" is not displayed when the switch is on or
"0" is not displayed when the switch is off, replace registration
switch.
Run maintenance item U031 and turn the eject switch on and off
manually. If "1" is not displayed when the switch is on or "0" is
not displayed when the switch is off, replace eject switch.
Run maintenance item U031 and turn the feedshift switch on
and off manually. If "1" is not displayed when the switch is on or
"0" is not displayed when the switch is off, replace feedshift
switch.
Reinsert the connector. Also check for continuity within the con-
nector cable. If none, remedy or replace the cable.
Check for continuity across each switch. If there is no continuity
when the switch is on, replace it.
Check for continuity. If none, repair.
Locate the source of noise and remove.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
