Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
1-1-1
1-1-1 Specifications
Type ............................................... Desktop laser printer
Printing system............................... Electro photographic system
Paper.............................................. Cassette: Plain paper (60 to 90 g/m
2
), Thick paper (90 to 105 g/m
2
)
MP tray: Plain paper (60 to 90 g/m
2
), Thick paper (90 to 200 g/m
2
)
Special paper: Transparencies, label paper, envelopes and colored paper
Note: Use the MP tray for special paper.
Printing sizes .................................. Maximum: A3/Ladger
Minimum: A5R /5
1
/
2
" × 8
1
/
2
" (When the MP tray is used)
Print speed ..................................... FS-9120DN model [Cassette/MP tray]
A4: 36 pages/28 pages per min.
B4: 20 pages/18 pages per min.
A3: 20 pages/18 pages per min.
Letter: 36 pages/27 pages per min.
Legal: 20 pages/18 pages per min.
Ledger: 20 pages/18 pages per min.
FS-9520DN model [Cassette/MP tray]
A4: 51 pages/31 pages per min.
B4: 26 pages/23 pages per min.
A3: 26 pages/21 pages per min.
Letter: 51 pages/30 pages per min.
Legal: 26 pages/23 pages per min.
Ledger: 26 pages/20 pages per min.
First print time ................................ FS-9120DN model
Approx. 5 s or less (A4, during printing)
Approx. 30 s or less (A4, during sleep mode)
FS-9520DN model
Approx. 7 s or less (A4, during printing)
Approx. 32 s or less (A4, during sleep mode)
Warm-up time ................................. Approx. 25 s or less (room temperature 23 °C/73.4 °F, 60% RH,
from power on/sleep mode)
Paper feed system ......................... 2 universal type cassettes, and MP tray
Paper loading capacity ................... Cassette: 500 sheets (75 g/m
2
, 0.11 mm)
MP tray: 200 sheets (75 g/m
2
, 0.11 mm)
Printout stacking capacity .............. Face down tray: 500 sheets with paper full sensor
Photoconductor .............................. a-Si drum (diameter 40 mm)
Charging system ............................ Single positive corona charging
Exposure light source .................... Semiconductor laser
Exposure scanning system ............ Polygon mirror
Developing system ......................... Dry, reverse developing (magnetic brush)
Developer: 1-component, magnetism toner
Toner replenishing: automatic from a toner container
Transfer system ............................. Transfer roller
Separation system ......................... Separation electrode
Fixing system ................................. Heat roller and press roller
Charge erasing system .................. Exposure by cleaning lamp (LED array)
Cleaning system ............................ Cleaning blade
Controller hardware........................ CPU: Power PC750CX 400 MHz (FS-9120DN model)
Power PC750CX 500 MHz (FS-9520DN model)
Code ROM: 4 MB (2 system DIMM PWBs in sockets)
Font ROM: 4 MB (PCL6 and KPDL3)
Main RAM: 32 MB, expandable up to 544 MB (FS-9120DN model)
64 MB, expandable up to 576 MB (FS-9520DN model)
Option expanding RAM: 2 sockets (Maximum 288 MB, including the standard RAM)
Option memory card: 1 slot (CompactFlash card)
Option interface: 2 slots (KUIO-LV)
Host computer interface ................. Parallel: Bi-directional parallel (IEEE 1284 Nibble/ECP mode)
USB: USB2.0 High-speed
Network: 10Base-T/100Base-TX
Option network interface card (KUIO slot No. 2): 10Base-T/100Base-TX/10Base-2

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
