FS-9120DN/9520DN
1-6-23
1-6-8 PWBs
(1) Detaching and refitting the main controller PWB
Follow the procedure below to detaching and refitting the main controller PWB.
Procedure
1. Remove the two screws.
2. Draw the main controller PWB.
Figure 1-6-49
Main controller PWB
