Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-2-3
20. Registration switch (RSW) ........................... Controls the secondary paper feed start timing.
21. Eject switch (ESW) ...................................... Detects a paper misfeed in the fuser section.
22. Feedshift switch (FSSW) ............................. Detects a paper misfeed in the switchback section in a duplex print.
23. Toner sensor (TNS) ..................................... Detects the toner density in the developing unit.
24. Toner container detection switch
(TCDSW) ..................................................... Detects the presence of the toner container.
25. Toner container sensor (TCS) ...................... Detects the quantity of toner in a toner container.
26. Waste toner box detection switch
(WTDSW) .................................................... Detects the presence of the waste toner box.
27. Overflow sensor (OFS) ................................ Detects when the toner disposal bottle is full.
28. Humidity sensor (HUMSENS) ...................... Detects absolute humidity.
29. Fuser unit thermistor 1 (FTH1) .................... Detects the heat roller temperature.
30. Fuser unit thermistor 2 (FTH2) .................... Detects the heat roller temperature.
31. Front cover switch (FRCSW) ....................... Detects the opening and closing of the front cover.
32. Conveying cover switch (CCSW) ................. Detects the opening and closing of the conveying cover.
33. Side cover switch (SCSW) ........................... Detects the opening and closing of the side cover.
34. Paper full sensor (PFS) ............................... Detects whether the face-down tray is full.
35. Duplex paper conveying switch
(DUPPCSW) ................................................ Detects a paper jam in the duplex unit.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
