Kyocera FS-9120DN Service Manual

FS-9120DN/9520DN
2-3-3
Terminals (YC) Voltage Remarks
TB-1 TB-2 120 V AC 120 V AC supply, input
TB-1 TB-2 220-240 V AC 220-240 V AC supply, input
TB-4 TB-5 120 V AC 120 V AC supply for POWSW, output
TB-4 TB-5 220-240 V AC 220-240 V AC supply for POWSW, output
1-1 1-2 24 V DC 24 V DC supply for SSW1, output
1-5 1-2 3.4 V DC 3.4 V DC supply for EPWB, output
1-8 1-2 5 V DC 5 V DC supply for EPWB, output
1-10 1-2 24 V DC 24 V DC supply for EPWB, output
2-1 2-2 0 - 5 V DC Heater current monitor signal, output
2-3 2-2 0/5 V DC FH-S on/off, input
2-4 2-2 0/5 V DC FH-M on/off, input
2-5 2-2 5 V DC 5 V DC supply from EPWB, input
2-6 2-2 0/5 V DC (pulse) Zero-cross signal, input
3-1 3-5 24 V DC 24 V DC supply for finisher*, output
3-2 3-6 24 V DC 24 V DC supply for finisher*, output
3-3 3-7 24 V DC 24 V DC supply for finisher*, output
3-4 3-8 24 V DC 24 V DC supply for finisher*, output
3-10 3-9 5 V DC 5 V DC supply for finisher*, output
3-11 3-12 5 V DC 5 V DC supply for paper feeder PF-70*/PF-75*, output
3-14 3-13 24 V DC 24 V DC supply for paper feeder PF-70*/PF-75*, output
3-15 3-18 24 V DC 24 V DC supply for switchback unit*, output
3-16 3-19 24 V DC 24 V DC supply for switchback unit*, output
3-17 3-20 5 V DC 5 V DC supply for switchback unit*, output
4-1 6-1 0/24 V DC CFM4 on/off, output
4-2 6-1 24 V DC 24 V DC supply for CFM4, output
5-1 5-3 120/0 V AC FH-M on/off, output
5-1 5-3 220-240/0 V AC FH-M on/off, output
5-2 5-3 120/0 V AC FH-S on/off, output
5-2 5-3 220-240/0 V AC FH-S on/off, output
8-1 2-2 0/5 V DC CFM4 remote signal, input
8-3 2-2 0/5 V DC SLEEP signal, input
*Optional.

Kyocera FS-9120DN Specifications

General

I/O ports	1 x Fast Ethernet 10/100 Base TX; 1 x High speed bi-directional parallel (IEEE 1284); 1 x USB 2.0 (High-Speed); 1 x KUIO LV Option-Interface slot.
Custom media sizes	88 x 148 mm - 297 x 450 mm
Power requirements	AC 220/240 V 50/60 Hz
Standard input trays	2 x 500
Recommended media weight	60 - 105 g/m²
Power consumption (active)	920 W
Maximum print size	297 x 420 mm
Maximum ISO A-series paper size	A3
Color	No
Print technology	Laser
Time to first page (black, normal)	7 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Memory slots	2
Storage media	HDD
Processor model	Power PC 750CX
Built-in processor	Yes
Maximum internal memory	544 MB
Internal storage capacity	20 GB
Sound power level (standby)	39 dB
Sound pressure level (printing)	53 dB
Total input capacity	1200 sheets
Maximum input capacity	4200 sheets
Paper tray 2 input capacity	200 sheets
Maximum duty cycle	55000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	160 W
Power consumption (PowerSave)	12 W

Weight and Dimensions

Dimensions (WxDxH)	585 x 639 x 615 mm
