Kyocera FS-C5100DN Service Manual

2HL/2HM/2HN
1-4-8
2102 Developing motor MCY error
XXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXX
X
Defective harness
between develop-
ing motor MCY and
engine PWB
(YC27), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective drive
transmission
system of the
developing motor
MCY.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective develop-
ing motor MCY.
Replace the developing motor MCY.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
2250 Main charger cleaning motor error
XXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXXXXXXXX
X
Defective harness
between main
charger cleaning
motor and engine
PWB (YC36), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the main
charger cleaning
motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main
charger cleaning
motor.
Replace the main charger cleaning motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
2500 Paper feed motor error
The main motor ready input is not given
for 5 s during the main motor is ON.
Defective harness
between paper
feed motor and
engine PWB (YC3/
YC4), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drive
transmission sys-
tem of the paper
feed motor.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective paper
feed motor.
Replace the paper feed motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures
