Kyocera FS-C5100DN Service Manual

2HL/2HM/2HN
1-1-7
1-1-2 Parts names
(1) Overall
21/23 ppm (500-sheet) model and 26/28 ppm (500-sheet) model
Figure 1-1-1
9
10
11
12
13
14
15
21
17
16
18
19
20
3
4
22
5
6
7
8
8
8
8
7
1
2
21/23 ppm
(500-sheet) model
1. Operation panel
2. Top cover (Top tray)
3. MP tray
4. Cassette
5. Power switch
6. Left cover
7. Waste toner box
8. Main charger unit
9. Toner container M
10. Toner container C
11. Toner container Y
12. Toner container K
13. Duplex unit B
14. Fuser cover A
15. Envelope switch
16. USB interface
17. AC inlet
18. USB memory slot
19. Network interface
20. Network indicator
21. Optional interface slot
22. Right cover
