Using the Operation Panel 2-35
Entering the Width and Length
Enter the paper size for X Dimension and Y Dimension as shown in
the figure.
1 When the unit of measurement is set, press V.
>>X Dimension appears (the paper width setting).
2 Press [OK]. A blinking cursor (_) appears.
3 Press U or V to increase or decrease the value of the figure where
the cursor is blinking and display the desired width.
Acceptable paper widths are as follows:
• Cassette : 105 to 216 mm
• Paper Feeder PF-500/PF-510 (optional) : 92 to 216 mm
4 Display the paper width and press [OK].
5 When the width is set, pressV. >>Y Dimension appears (the paper
length setting). Set the desired length in the same way as the width.
Acceptable paper lengths are as follows:
• Cassette : 148 to 356 mm
• Paper Feeder PF-500/PF-510 (optional) : 162 to 356 mm
6 Display the paper length, press [OK].
7 Press [MENU]. The display returns to Ready.
