Kyocera FS-C5400DN User Manual

4-118 Using the Operation Panel
Drum (Drum/Refresh mode setting)
This sets the refresh mode for the drum. When the printing quality
declines, refreshing the drum can restore the printing quality. This is
primarily used for maintenance by service personnel.
1 In the Service Setting menu, press U or V to select Drum.
2 Press [OK]. A confirmation screen appears.
Press [Yes] ([Left Select]). Carry out drum refresh.
Pressing [No] ([Right Select]) returns you to the Service Setting.
menu screen without refreshing the drum.
LSU (LSU cleaning mode setting)
This sets the cleaning mode for the LSU. When the printing quality
declines, cleaning the LSU can restore the printing quality. This is
primarily used for maintenance by service personnel.
1 In the Service Setting menu, press U or V to select LSU.
2 Press [OK]. A confirmation screen appears.
Press [Yes] ([Left Select]). Carry out the LSU cleaning.
Pressing [No] ([Right Select]) returns you to the Service Setting
menu screen without cleaning the LSU.
DRUM2 (DRUM2 mode setting)
Under high-temperature and high-humidity environment, drum refresh
mode (See above.) can take longer to start. Turning DRUM2 mode to On
will allow drum refresh mode to start without delay even under such
environment. However, power consumption of the machine during
sleeping mode will increase. This mode is primarily used by service
personnel.
1 In the Service Setting menu, press U or V to select DRUM2.
2 Press U or V to select a setting and then press [OK]. The Service
Setting selection menu list reappears.
Drum
Are you sure?
[ Yes ] [ No ]
LSU
Are you sure?
[ Yes ] [ No ]
DRUM2: a b
1 Off
2 On
[ Exit ]

Kyocera FS-C5400DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Maximum internal memory	1280 MB
Sound power level (standby)	36, 36.1 dB
Sound pressure level (printing)	52.1, 55 dB
Total output capacity	500 sheets
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Plain paper, Recycled paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Network ready	No
Mobile printing technologies	-
Compatible operating systems	Mac OS X 10.2, UNIX, LINUX
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	91 W
Power consumption (printing)	608 W
Power consumption (PowerSave)	10 W
Display	LCD
Certification	GS, TÜV, CE
Product color	Gray
Maximum duty cycle	150000 pages per month
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	510 mm
