Kyocera FS-C5400DN

Maintenance 5-9
3 Wipe away the paper dust on the registration roller, the paper ramp
and paper guide using the cleaning cloth.
4 Push the front cover back in completely.
Paper Ramp
Transfer Belt
(Black)
Dry Cloth
Registration
Roller (Metal)
Transfer Roller
(Black)
Duplex Unit
Paper
Transfer Unit
Paper guide
Note Be careful not to touch the black transfer roller and
black transfer belt during cleaning as this may adversely
affect print quality.
Note Take care not to get your hands caught in the front
cover when you close it.
