3-74
Enhancement device setup procedure > Optional device installation
[CONFIDENTIAL]
83
Set the horizontal transport unit on the slide rails.
84
Attach four screws [A] provided with this option (Screw x4: M3x6).
• When holding the horizontal transport unit, hold its rear center and front center.
• Hang the tabs located at the four corners of the slide rail into the cutouts in the horizontal transport unit.
To Next Page
