Kyosan K5BMC User Manual

MTC Failure Display Specification for K5BMC EI
Document No. Z914-C73000030E Ver. 5
12. Feb. 2011 P 15 / 25
4.2.3 MMIF Sub-Rack
1) LINEM2
2) MMIF2
4.2.4 Journal Module
*The corresponding yellow message pop-up screen will appear on MTC for the ease of maintenance.
Tes t
No.
Check Item Message in case of failure occurs/recovers Relay Name
Nomal
bit status
Note
1 ETCtrl Data OE Transform MMIF_S1_LINEM2 ET-Ctrl-Data-OE_fail S1-LINEM-OE-FL
1
*
2 ET Indic. Data EO Transform MMIF_S1_LINEM2 ET-Indic.-Data-EO_fail S1-LINEM-EO-FL
1
*
3 DC24/DC5 MMIF_S1_LINEM2 DC24/DC5_fail S1-LINEM-D24-5-FL
1
*
4 ETCtrl Data OE Transform MMIF_S2_LINEM2 ET-Ctrl-Data-OE_fail S2-LINEM-OE-FL
1
*
5 ET Indic. Data EO Transform MMIF_S2_LINEM2 ET-Indic.-Data-EO_fail S2-LINEM-EO-FL
1
*
6 DC24/DC5 MMIF_S2_LINEM2 DC24/DC5_fail S2-LINEM-D24-5-FL
1
*
Tes t
No.
Check Item Message in case of failure occurs/recovers Relay Name
Nomal
bit status
Note
1 ETCtrl Data Rx
MMIF_S1_MMIF2-n ET-Ctrl-Data-Rx_fail S1-MM-n-Rx-FL
1
n=1 *
2 ET Indic. Data Tx
MMIF_S1_MMIF2-n ET-Indic.-Data-Tx_fail S1-MM-n-Tx-FL
1
n=1 *
3 MMIF2 ID CHECK
MMIF_S1_MMIF2-n MMIF2-ID-CHECK_fail S1-MM-n-IDCHECK-FL
1
n=1 *
4 I/O-1
MMIF_S1_MMIF2-n I/O_fail S1-MM-n-IO-FL
1
n=1 *
Tes t
No.
Check Item Message in case of failure occurs/recovers Relay Name
Nomal
bit status
Note
1
ZPEN3 JOURNAL_ ZPEN3 Card_fail
ZPEN3-FL
1
*
2
ZNIO2- S1 JOURNAL_ZNIO2_S1 Card_Main_fail ZNIO2-S1_M-FL
1
*
3
ZNIO2 -S2 JOURNAL_ZNIO2_S2 Card_Main _fail ZNIO2-S2_M-FL
1
*
4
ZSIO2 JOURNAL_ ZSIO2 Card_Main_fail ZSIO2_M-FL
1
*
5
DC24/DC5 JOURNAL_DC/DC Converter_fail
J-DD_CON-FL
1
*
6 ZNIO2-S1 Rx JOURNAL_ZNIO2_S1 Rx_fail
ZNIO2-S2-Rx-FL
1
*
7 ZNIO2-S2 Rx JOURNAL_ZNIO2_S2 Rx_fail
ZNIO2-S2-Rx-FL
1
*
8 ZSIO2 Tx/Rx JOURNAL_ ZSIO2 Tx/Rx_fail ZSIO2-Rx-FL
1
*
9 ZPEN3 JOURNAL Rx_stop_fail J-RX-STOP-FL
1
*
10 ZPEN3 JOURNAL Rx_data_fail J-RX-DATA-FL
1
*
