BAG
B
フロントバルクへッド
FrontBulkhead
ドライブガイド
DriveGuide
1.5
mm
重要! 向きに注意
Important!Attentiontothedirection
図の位置に合わせます。
Lineupasshowninthefigure
向き注意凹前側!
Attentiontothedirection
Markingisfrontside.
向き注意凹前側!
Attentiontothedirection
Markingisfrontside.
締めすぎ注意!
Donotovertighten!
1
2
Chain Drive
Belt Drive
OT218S
bb
OT242
TP F/H M3x12mm
cc
OT242
TP F/H M3x12mm
cc
OT242
TP F/H M3x16mm
dd
BRG014
BRG014
OT241
TP F/H
M2x8mm
bb
OT241
bb
OT206
aa
OT206
bb
OT202
44
OT206
33
OT206
22
OT206
44
OT206
11
OT202
22
ベルトドライブの 場 合
チェーンドライブの 場 合
締めすぎ注意!
Donotovertighten!
5
6
