カウンターギヤ
CounterGear
アッパ ーロッド
UpperRods
SCW021
HD
x2pcs
5
mm
オプション ハイパワーモーターにお勧め!
OptionRecommendedtoahigh-powermotor!
SC216
Slipper Pad
SC215
Slipper Plate
OT221
cc
OT235R / OT236R
aa aa
OT225
aa
OT225
bb
OT225
dd
OT225
ee
OT234
bb
LA43
11
LA43
11
1-N4056FN
W0201
W0201
重要! 向きに注意
Important!Attentiontothedirection
向きに注意図のようにフランジを外側にセットします。
Flangeissetoutsideasshowninthecarefulfigure
inthedirection.
シャフトの面まで締め込みます。
Tighteneduptothefaceofashaft.
重要! 向きに注意
Important!Attention
tothedirection
19mm
20.5mm
2x
Front
Rear
2x
脂分をふき取ってください。
Pleasewipeupoil.
