ARCS
®
WIDE SYSTEM
ARCS
®
FOCUS SYSTEM
user manual
VERSION 4.0
ARCSWIFO_UM_EN_4.0
www.l- acoustics.com
12
3 LOUDSPEAKER CONNECTION
3.1 Connectors
Internal pinout for L-ACOUSTICS
®
ARCS WIDE/FOCUS and SB18m
SpeakON
®
points 1+ 1 - 2 + 2 -
Transducer connectors
+
-
Not used
Not used
