Loudspeaker configurations
Separated
The [SYVA] preset allows for a reference frequency response in medium throw applications.
The [SYVA LOW_100] and [SYVA SUB_100] presets provide Syva Low and Syva Sub with an upper frequency limit at
100 Hz.
[SYVA SUB_100] polarity is reversed to optimize Syva Sub acoustic summation with
Syva/Syva Low.
> 60 cm / 24 in
Enclosures Syva Syva Low Syva Sub
Presets [SYVA] [SYVA LOW_100] [SYVA SUB_100]
Frequency range (-10 dB) 27 Hz - 20 kHz
Grouping subwoofers
Place the subwoofer enclosures side by side. If not possible, the maximum distance between two adjacent
acoustic centers must be 1.7m if the upper frequency limit of the subwoofer system is at 100Hz.
Do not forget to add the geometric delays depending on the configuration.
No pre-alignement delay values are required for the Syva system.
13 Syva user manual (EN) version 1.0
