Loudspeaker connection
Connection to LA4X
Maximum number of enclosures per LA4X
enclosure max enclosures in parallel max enclosures per controller
Syva 1 4
Syva Low 1 4
Syva Sub 1 4
Impedance load
Syva Syva Sub
1 enclosure: 8 Ω
Syva Low
1 enclosure: 4 Ω
Connecting 2-way passive enclosures or subwoofers
SP on speakON output
SP
SP
SP
SP
OUT1
OUT2
OUT3
OUT4
SP and SP-Y1 on speakON output
OUT1/OUT2
OUT3/OUT4
same as OUT1/OUT2
SP SP-Y1
CC4FP
CH(1) (OUT1)
CH(2) (OUT2)
Syva user manual (EN) version 1.0 16
