Loudspeaker connection
Syva Low and Syva Sub
Syva Low and Syva Sub are equipped with one 4-point speakON connector.
Use the labels to differentiate the subwoofers.
IN
IN
Syva Low Syva Sub
Internal pinout for L-Acoustics subwoofers
speakON points 1 + 1 - 2 + 2 -
Transducer connectors LF + LF - Not linked Not linked
Syva combined with Syva Low
Amplified controller damage
Do not use the speakON connector or screw terminals on Syva when using AutoConnect.
With Syva on top of Syva Low, AutoConnect is enabled and power is routed through the subwoofer connector plate to
the enclosure.
AutoConnect internal pinout
AutoConnect points 1 + 1 - 2 + 2 -
Transducer connectors LF + LF - MF/HF+ MF/HF-
15 Syva user manual (EN) version 1.0
