System components
System components
Loudspeaker enclosures
Syva 2-way-passive enclosure: 6 x 5'' LF + 3 x 1.75'' HF diaphragm
Syva Low High power low frequency subwoofer: 2 x 12'' LF
Syva Sub Infra low frequency subwoofer: 1 x 12'' LF
Powering and driving system
LA4X / LA8 / LA12X Amplified controller with DSP, preset library and networking capabilities
LA-RAK Touring rack containing three LA8 and power, audio and network distribution
LA-RAK II Touring rack containing three LA12X, LA-POWER II for power distribution and LA-PANEL II for
audio and network distribution
L-CASE 2U Electronics transport and protection case
Refer to the LA4X / LA8 / LA12X user manual for operating instructions.
Loudspeaker cables
DO 8-point PA-COM loudspeaker cables (4mm² gauge)
DO cables come in three sizes: DO.7 (0.7m/2.3ft), DO10 (10m/32.8ft) and DO25
(25m/82ft)
DO3WFILL breakout cable for one 2-way active enclosure and two passive enclosures (4mm² gauge)
8-point PA-COM to 1 x 4-point speakON and 2 x 2-point speakON
DOFILL-LA8 breakout cable for two 2-way active enclosures (4mm² gauge)
8-point PA-COM to 2 x 4-point speakON
DOSUB-LA8 breakout cable for four passive enclosures (4mm² gauge)
8-point PA-COM to 4 × 2-point speakON
SP-Y1 breakout cable for two passive enclosures (2.5mm² gauge) provided with a CC4FP adapter
4-point speakON to 2 × 2-point speakON
SP cables 4-point speakON loudspeaker cables (4mm² gauge)
SP cables come in four sizes: SP.7 (0.7m/2.3ft), SP5 (5m/16.4ft), SP10 (10 m/32.8ft) and
SP25 (25m/82ft)
Information about the connection of the enclosures to the LA amplifiers is given in this
document.
Refer to the LA4X / LA8 / LA12X user manual for detailed instructions about the whole cabling scheme, including
modulation cables and network.
Rigging elements
Rigging elements or procedures are not presented in this document.
Refer to the Syva rigging manual.
Syva user manual (EN) version 1.0 6
