L-Acoustics S Series User Manual

Loudspeaker connection
Connection to LA8
Maximum number of enclosures per LA8
enclosure max enclosures in parallel max enclosures per controller
Syva 2 8
Syva Low 1 4
Syva Sub 2 8
Impedance load
Syva Syva Sub
1 enclosure: 8 Ω
2 enclosures in parallel: 4 Ω
Syva Low
1 enclosure: 4 Ω
Connection to LA12X
Maximum number of enclosures per LA12X
enclosure max enclosures in parallel max enclosures per controller
Syva 3 12
Syva Low 2 6
Syva Sub 3 12
Make sure the total number of connected enclosures does not exceed the maximum number
of enclosures per controller.
LA12X can drive up to two Syva Low per output, but no more than six per controller.
Impedance load
Syva Syva Sub
1 enclosure: 8 Ω
2 enclosures in parallel: 4 Ω
3 enclosures in parallel: 2.7 Ω
Syva Low
1 enclosure: 4 Ω
2 enclosures in parallel: 2 Ω
Syva user manual (EN) version 1.0 18
