Loudspeaker configurations
Syva colinear source with LF extension and subwoofer
With Syva Sub, the Syva system bandwidth is extended down to 27 Hz.
Syva, Syva Low and Syva Sub are driven by the LA4X / LA8 / LA12X amplified controllers.
Coupled
The [SYVA LOW SYVA] hybrid preset enables acoustic coupling when Syva is on top of Syva Low (AutoConnect) or
within a 60 cm (24 in) distance.
To use [SYVA LOW SYVA], connect Syva and Syva Low to the same amplified controller output.
Use Autoconnect or an SP-Y1 cable. Refer to Connecting hybrid configurations (p.17) for LA4X and
Connecting hybrid configurations (p.19) for LA8 or LA12X.
The [SYVA SUB_100] preset provides Syva Sub with an upper frequency limit at 100 Hz.
[SYVA SUB_100] polarity is reversed to optimize Syva Sub acoustic summation with
Syva/Syva Low.
< 60 cm / 24 in
Enclosures Syva Syva Low Syva Sub
Presets [SYVA LOW SYVA] [SYVA SUB_100]
Frequency range (-10 dB) 27 Hz - 20 kHz
Grouping subwoofers
Place the subwoofer enclosures side by side. If not possible, the maximum distance between two adjacent
acoustic centers must be 1.7m if the upper frequency limit of the subwoofer system is at 100Hz.
Do not forget to add the geometric delays depending on the configuration.
No pre-alignement delay values are required for the Syva system.
Syva user manual (EN) version 1.0 12
