L3 Communications FA2100 - Rear Panel Assy

COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
FA2100CVR
Page 309
Nov. 01/98
Disassembly
23–70–04
(9) Package Acquisition Processor PWA in a static-resistant container for shipment to
the factory for repair.
(1‐5)
Chassis
(1-95)
Qty. 8
Chassis Cover
Assy
(1-20)
(1-180)
Qty. 10
J1
J3
J4
J2
Acquisition
Processor PWA
(AP)
(1‐175)
Audio Compressor
PWA (AC)
(1-155)
Aircraft Interface
PWA (AI)
(1-105)
W003
(1-165)
W001
(1-170)
Rear Panel
Assy
(1-90)
J5
Figure 306. Acquisition Processor PWA Removal Diagram
Dec. 09/1
3
Rev. 13 Page 309
