COMPONENT MAINTENANCE MANUAL
AVIATION RECORDERS
FA2100CVR
Highlights
23–70–04
RECORD OF HIGHLIGHTS
Issue Revision Date of
Change
Comments
Revision 13 Dec. 09/13 Assembly, Dissassembly, and IPL updated to re-
flect MOD DOT 13. ROSE/ROC/ADLP version
numbers updated. Software checksums updated.
Model configuration tables added for clarity. Au-
tomatic Test Section revised
Revision 12 Jul. 03/13 Corrected page number errors and updated the
LOEP and Table of Contents.
Revision 11 May 21/13 Added automatic testing section. Added p/n
2100−1027−02. Revised IPL.
Revision 10 Jun. 15/12 Added configuration
Updated Numerical Parts Index to reflect
changes in service bulletins.
Changed output levels for PI MOD DOT #8
Updated the IPL to reflect p/n 2100−1025−24.
Revision 09 Apr. 30/10 Added TSO−C123b. Added Onboard Mainten-
ance System interface and CVR Datalink Input
Interface descriptions. Added software FDP
checksum list for P/Ns 2100−1025/6−XX. up-
dated ROSE software to 4.X
Revision 08 Jul. 30/09 Revised set up figures with Support Equipment in
both Test and Special tools sections.. Updated
procedures in Section 200 Automatic Testing.
added new software for the CVR P/N
2100−1025−22 and 2100−1026−02
Revision 07 Dec. 01/08 Updated for Revision. Added SB011, SB012,
SB013, SB014, SB015, SB 016. Changed the
List of Effective Pages to reflect the Revision 07,
added divider to Table of Contents. Added refer-
ence to ROC/6, updated date for Autotest confir-
mation. Added Beacon Test note, changed con-
tent per SB013, corrected reference to Data Link
(ATC) Interface. Added Beacon Test note, added
Acquisition Processor configuration, added refer-
ence to ROC/6. Updated part numbers, correc-
ted test setup diagram, added RIU power cau-
tions, verified ROC/6 part list. Added configura-
tion. Updated Test Equipment lists, corrected test
diagram. Updated Numerical Parts Index to re-
flect changes in service bulletins. Updated the
IPL to reflect p/n 21001026−02.
Rev. 13 Page v
Dec. 09/13
