INSTALLATION
Check the appliance is electrically safe when you have nished.
Fitting the Flue Grille
Before tting the ue grille the fan cover will require removal.
To do this remove the two upper screws and lift clear
(Fig.7.5). Unscrew and remove the two screws from the
upper rear corners of the cooker (Fig.7.5). These will be used
to secure the grille.
The ue grille is packed separately.There are four screws
supplied tted to the underside of the grille. These will need
to be unscrewed until there is a space of 7 mm between the
underside of the screw head and the grille (Fig.7.6).
Locate the grille with the screw heads inside the keyhole slots
in the cooker. Gently push the grille towards the hob to locate
(Fig.7.7).
Fix the grille in place using the two screws removed
previously (Fig.7.8). Tighten the four screws on the underside
of the grille.
Ret the fan cover and two screws.
7 mm
Fig.7.5
Fig.7.6
Fig.7.7
Fig.7.8
