10. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Below the storage drawer. Remove the storage drawer (see ‘Unpacking the Cooker’)
COUNTRIES OF DESTINATION: GB, IE, FR, NL, DE, IT, ES, RU, BE, AT, LU.
Connections
Electric 230 / 400 V 3N 50 Hz
Induction Hob
Induction Hob Non-Boost Boost
Left-hand Front
1.40 kW 2.20 kW
Left-hand Back 1.85 kW 3.00 kW
Centre 2.30 kW 3.70 kW
Right-hand Front 1.85 kW 3.00 kW
Right-hand Rear 1.85 kW 3.00 kW
Dimensions
Overall height minimum 910 mm
maximum 937 mm
Overall width 1092 mm See ‘Positioning the Cooker’.
Overall depth including handles
720 mm
Overall depth excluding handles 650 mm
Minimum space above hotplate 800 mm
Ovens
Ovens Left-hand Multi-function Oven Right-hand Fan Oven
Fan element 2.50 kW 2.50 kW
Top element 1.20 kW
Browning element 1.15 kW
Bottom element 1.00 kW
Ovens Multi-function Forced Air Convection
Energy eciency class: on a scale of A (more ecient) to G (less ecient) A A
Energy consumption based on standard load 0.95kWh 0.90kWh
Usable volume (litres) 69 69
Size Large Large
Time to cook standard load 41 minutes 38 minutes
Baking area 1400cm
2
1400cm
2
Maximum total electrical load at 230V approximate total including oven fan etc: 16.2 kW.
Total Nominal Load for Induction Hob at 230 V = 9.25 kW.
Total Boost Load for Induction Hob at 230 V = 11.1 kW.
915 / 942 mm
939 mm minimum
