La Gard 3000 - Dead Bolt;Spring Bolt Installation; Battery Installation

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page9
DEAD BOLT/SPRING BOLT
1.Mountthedialplate(p/n3752)centeredonthethroughhole(Figure6).AttachthedialplatewiththetwomountingscrewsUS8-32
(US)ortheM4-0.7(metric)..
2.Measuretotalmountingthickness(doorthickness+mountingplate).(Figure9.)
3.Cutthespindletoalengthof1.06”(27mm)plusthetotalmountingthickness.
NOTE: the spindle must be deburred .
4.Insertthespindleintothekeypad,androutethecableinthegrooveofthespindle(Figure7).
5.Routethecableeitherunderthespindleorbetweenthecircuitboardandthespindle.
6.Slidethebearingplate(p/n2674)overthecable,andpressontothefastenersontheEntryDevice(Figure7).
NOTE: It is important to make sure the cable will not rub on the dial plate after assembly.
7.FeedtheEntryDevice’scableandspindlethroughthespindle/cableholefromthefrontofthesafedoor.
WARNING: Spring and blocking pin are NOT installed when Entry Device is used with either the dead bolt or spring bolt locks.
8.Rotatethekeypadapprox.30°counter-clockwiseandplacekeypadbushingsintothe
9.Thenturnthekeypadclockwiseuntilthekeypadisvertical.
10. Thespindleshouldprotrudebetween.300"-.350"(8-9mm)throughthesafedoor.
11. Slidethecableprotector(p/n2754)overthecableandspindle,untiltheatsiderestsagainsttheinsideofsafedoor.Routethe
  cablethroughthegrooveofthecableprotector.
12. Gentlypullonthecabletoassurethatthereisnoexcesscableinthespindleholethatwouldrubonthemetaldoor.
13. Installthelockwiththeboltextendedontothespindle.Refertolockinstallationinstructions
  whichareavailableatwww.kaba-mas.com.
BATTERY INSTALLATION
1.Ifinstalled,removeblackplasticbatterycompartmentcover(locatedatthebottomofthe
 keypad)bygentlypullingdownwardonitshandle.
2.Allowthebatteryconnectoranditsattachedleadstodropdownandoutofthebattery
 compartment.Ifitdoesnotdrop,gentlypullonthebatteryconnectoruntilitdoes.
CAUTION! Hold onto battery terminal connector to avoid pulling the wires out of housing.
3.Connectanew9-Voltalkalinebatterytothebatteryconnector.
4.Pushthebatteryandtheleadscompletelyintothebatterycompartment.
5.Installthebatterycoverbyplacingonesideofthecoverinpositionandthenpressingthe
 othersideintopositionwithyournger.
Figure9
Figure9
Dead/SpringBolt
DOOR
MOUNTING PLATE
TotalMountingThickness=doorthickness
+mountingplate
