La Gard 3000 - 3000 and 3715 Round Entry Device Installation; Installing Batteries

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page4
The3000and3715EntryDeviceisdesignedwithkeyholeslotsforease
ofmountingandbatteryreplacement.
1.Installthetwo#8-32shoulderscrews(US)ortheM4-0.7shoulder
 screws(metric)tomounttheEntryDevicetothedoor.
2.Feedthekeypadcablethroughthespindlecableholefromthefront
 ofthesafedoor.Leaveapproximately2inches(50mm)ofthecable
 extendedoutthefrontofthecontainerdoor,toallowfor
 batteryreplacement.
3.PositiontheEntryDeviceoverthemountingscrewsandthensidethe
 EntryDevicedownontothemountingscrews.(Figures1&2)
4.EnsurethattheEntryDevicecableisrunningthroughthechannelat
 thebackofthelock.
INSTALLING BATTERIES
1.Slidethekeypadhousingupandcarefullypullawayfrommountingsurfacetoexposebatterycompartment.
CAUTION! Hold onto the battery connector to avoid pulling the wires out of the board.
2.Connectanew9-Voltalkalinebatterytothebatteryconnector.
3.Pushthebatteryandtheleadscompletelyintothebatterycompartment.
4.Repeatprocedureforsecondbattery(3000only).
5.Carefullypositionthekeypadoverthemountingscrews
 andslidethekeypadhousingdown.Ensuretherearenowires
 orcablestrappedbetweentheEntryDeviceandthesafedoor.
KeyholeSlots
Figure1
Figure2
9VoltBattery
KeyholeSlots
3000
3000
3715
3715
3000 AND 3715 ROUND ENTRY DEVICE
