La Gard 3000 - 3710 Angular Entry Device Installation; Alternate Installation Method; Battery Installation

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page7
The 3710 Entry Device comes with the mylar portion of the keypad unattached.
1.Feedthekeypadcablethroughthespindlecableholefromthefrontofthesafedoor.(Figure5).
2.PositiontheEntryDeviceoverthescrewholesonthedoor,andliftthekeypadtoexposethe
 mountingholes.
3.Installthetwo#8-32screws(US)ortheM4-0.7screws(metric)tomounttheEntryDeviceto
 thedoor.
NOTE: Ensure that the battery connector is routed through the battery open at the bottom of the
housing, and no wires are pinched under the housing.
4.Removetheadhesivestripfromthebackofthekeypadandcarefullyalignbeforeadheringto
 thehousing(Figure6).Priortoadhering,makesurethatthehousingiscompletelyfreeofdebris
 suchaslings,dust,etc.,forthebestpossiblecontact.
WARNING: Once installed, the Entry Device cannot be removed from the safe door without causing
physical damage to the keypad.
5.EnsurethattheEntryDevicecableisrunningthroughthechannelatthebackofthelock.Refertolock
 installationinstructionswhichareavailableatwww.kaba-mas.com.
ALTERNATE INSTALLATION
Theoptionadapterplate(p/n3716)maybeusedtomountthe3710EntryDevicetoasafewith
verticalmountinghole(12and6o’clock).
1.Mounttheadapterplatecenteredonthethroughhole.Attachthedial
 platewiththetwomountingscrewsUS8-32(US)ortheM4-0.7(metric).
 Thenfollowtheaboveinstallationinstructions.
BATTERY INSTALLATION
1.Ifinstalled,removeblackplasticbatterycompartmentcover(locatedatthebottomofthekeypad)by
 gentlypullingdownwardonitshandle.
2.Allowthebatteryconnectoranditsattachedleadstodropdownandoutofthebattery
 compartment.Ifitdoesnotdrop,gentlypullonthebatteryconnectoruntilitdoes.
CAUTION! Hold onto battery terminal connector to avoid pulling the wires out of housing.
3.Connectanew9-Voltalkalinebatterytothebatteryconnector.
4.Pushthebatteryandtheleadscompletelyintothebatterycompartment.
5.Installthebatterycoverbyplacingonesideofthecoverinpositionandthenpressingthe
 othersideintopositionwithyournger.
3716
Figure5
Figure6
3710
3710 ANGULAR ENTRY DEVICE (ADDITIONAL INSTRUCTIONS 3716 ADAPTER)
