INSTALLING BATTERIES
The3035/3125EntryDevicerequiredeitherabatterybox(2788or4001),orabattery/alarmbox(2789or
4002)toprovidepowertothelock.
Mountthebatteryboxinsidethesafe,andconnectthecablecomingfromthebatteryboxdirectlyintothe
connectorportmarkedBATonthelock.
Small Battery and Battery/Alarm Box:
1.Opensafedoor.
2.Removebatteryboxcoverbypullingthefrontportionawayfromthesafedoor.
CAUTION! Hold onto the battery connector to avoid pulling the wires out of the board.
3.Connectanew9-Voltalkalinebatterytothebatteryconnector.
4.Pushthebatteryandtheleadscompletelyintothebatterycompartment.
5.Replacethecoverandtestthelockseveraltimesbeforeclosingthedoor.
Large Battery and Battery/Alarm Box:
1.Opensafedoor.
2.Removebatteryboxcoverbypullingthefrontportionawayfromthesafedoor.
3.Insertsixnew“C”cellalkalinebatteries
4.Replacethecoverandtestthelockseveraltimesbeforeclosingthedoor.
2788SmallBatteryBoxor
2789SmallBatteryAlarmBox
4001LargeBatteryBox
4002LargeBatteryAlarmBox
