La Gard 3000 - 3750, 3750-K, 3750 KE, & 3190 Entry Device Installation; Swing Bolt Installation

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page8
SWING BOLT
1.Mountthedialplate(p/n3752)centeredonthethroughhole(Figure6).Attachthedialplatewiththe
 twomountingscrewsUS8-32(US)ortheM4-0.7(metric).
2.Slidethebearingplate(p/n2674)overcableandpressontothefastenersonthe
 EntryDevice(Figure7).
3.Feedthekeypadcablethroughthespindlecableholefromthefrontofthesafedoor.
4.Insertthetwosprings(p/n2893)andblockingpins(p/n2894)intotheholeslocatedonthe
 backofthekeypad(Figure8).
5.Rotatethekeypadapprox.30°counter-clockwiseandplacekeypadbushingsinto
 thelargeopeningsonthedialplate.Thenturnthekeypadclockwiseuntilthe
 blockingpinclicks,andsecurestheEntryDevicetothesafedoor.
WARNING: Once installed, the Entry Device cannot be removed from the safe door without causing
physical damage to the Entry Device.
6.Wheninstallingthelock,ensurethattheEntryDevicecableisrunningthroughthe
 channelatthebackofthelock.Refertolockinstallationinstructionswhichare
 availableatwww.kaba-mas.com.
3750, 3750-K, 3750KE, & 3190 ENTRY DEVICE
3750, 3750-K
3190
SwingBolt
MountingScrews
Pins&Springs
InsertSprings&Pins
Figure6 Figure7 Figure8
