La Gard 3000 - 2666 Knob Assembly

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page11
Theholesrequiredtomounttheknobneedtobedrilled1.25"apartandmustbecenteredoverthespindlehole.
1.ToinstalltheKnobAssembly,removetheinsertfromthefrontoftheknob.
2.Cutthespindletoalengthof.820"(20.8mm)plusthedoorthickness(Figure14).
NOTE: the spindle must be deburred.
3.Installtheknobassemblyusingthetwo8-32X5/16phillipspanscrews.
4.Installthelock(withtheboltextended)ontothespindle,placingitushtothemountingsurface.Refertolockinstallation
 instructionswhichareavailableatwww.kaba-mas.com.
2666
Figure14
DOOR
MOUNTING PLATE
TotalMountingThickness=doorthickness
+mountingplate
2666 KNOB ASSEMBLY
