La Gard 3000 - General Information and Preparation; Safeguards for Mounting; Basic Tools and Materials Required; Preparation for New Installation

(P/N)762.128RevBEN05/10•©copyright2009-2010 Kaba Mas LLC
page1
Inordertomaintainthehighestqualitystandardsandensureaproblem-freeapplication,pleasereadthisguidethoroughlybefore
mountingtheinputunit.TheinstallationinstructionsarethebasisforSecurityAgencyApprovals.Thelockinstallationmustbedonein
accordancetotheseinstructionsinordertomaintainthelabeledapprovallevel.
SAFEGUARDS FOR MOUNTING
1.Onceanelectroniclockhasbeenmounted,nomoreweldingcanbedoneonthesafe.
2.Keepmetaldust,lings,etc.awayfromthelock.
3.Keepcablesawayfromsharpedgesandmovingparts.
4.Nevercarrykeypadsorlocksbythecable.
5.Use9-VoltALKALINEbatteriesonly.Theuseofahighquality,namebrandbattery(Energizer®orDuracell®)isrecommended.
BASIC TOOLS AND MATERIALS REQUIRED:
 • MediumPhillipsheadscrewdriver(#2)(recommendmagnetizedtip)
 • Smallatleordeburringstone
 • Tapemeasureorruler
 • ESDwristband
PREPARATION FOR NEW INSTALLATION: (IF REQUIRED)
1.Usethetemplateprovidedtoestablishtheexactlocations(relativetothespindlehole)ofthemountingholesfortheEntryDevice
 andthelockassembly.Besuretoconsiderthecablelengthfromtheentrydevicetothelock.
2.Thespindleholediametercanbeaminimumof.406"(10.3mm)toamaximumof.438"(11.1mm).The.406"(10.3mm)diameteris
 recommended.Spindleholemustbedeburred.
3.TheEntryDevicemountingscrewsrequiredrilledandtappedholesto3/8"(9.5mm)depthifpossible(minimum1/4"or6.4mm
 depthrequired.)Drilleitherthetwohorizontalmountingholesorthetwoverticalholes.
ForLockinstallationinstructions,referto717.088availableatwww.kaba-mas.com.
ELECTRONIC
ENTRY DEVICE
Installation Instructions
GENERAL INFORMATION
