Position Partnumber Description Comment Side
L1 L2xBEAD2M Inductor bead double 2 modules Top
L2 L2xBEAD2M Inductor bead double 2 modules Top
L7 1u2HD1.4_LAB Inductor 1,2uH axial LAB. Rev 01 Top
L101 L2xBEAD2M Inductor bead double 2 modules Top
L102 L2xBEAD2M Inductor bead double 2 modules Top
L107 1u2HD1.4_LAB Inductor 1,2uH axial LAB. Rev 01 Top
P1 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P2 - Not used Top
P3 Variant dependent, see separate list Top
P4a SO8P901M Socket 8pole 90dg 1module Top
P4b Variant dependent, see separate list Top
P5 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P6 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P101 NCJ6FI-H_NEU Connector XLR/J 3pole female+jack 90dg NEUTRIK NCJ6FI-H Top
P102 - Not used Top
P103 Variant dependent, see separate list Top
P104a SO8P901M Socket 8pole 90dg 1module Top
P104b Variant dependent, see separate list Top
P105 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P106 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P201 DI16P901M_PRE Dil socket 16pole 90dg 1 module PRECI-DIP 299-93-316-11-001 Top
P202 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P203 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
Q1 Q6015L5 Triac Q6015L5 Top
Q2 BC557B Transistor bipolar signal BC557B Top
Q3 BC547B Transistor bipolar signal BC547B Top
Q4 BC547B Transistor bipolar signal BC547B Top
Q5 BC557B Transistor bipolar signal BC557B Top
Q6 MPSA92 Transistor bipolar signal MPSA92 Top
Q7 MPSA42 Transistor bipolar signal MPSA42 Top
Q8 2N5457 Transistor Jfet signal 2N5457 Top
Q9 Variant dependent, see separate list Top
Q10 Variant dependent, see separate list Top
Q11 Variant dependent, see separate list Top
Q101 Q6015L5 Triac Q6015L5 Top
Q102 BC557B Transistor bipolar signal BC557B Top
Q103 BC547B Transistor bipolar signal BC547B Top
Q104 BC547B Transistor bipolar signal BC547B Top
Q105 BC557B Transistor bipolar signal BC557B Top
Q106 MPSA92 Transistor bipolar signal MPSA92 Top
Q107 MPSA42 Transistor bipolar signal MPSA42 Top
Q108 2N5457 Transistor Jfet signal 2N5457 Top
Q109 Variant dependent, see separate list Top
Q110 Variant dependent, see separate list Top
Q111 Variant dependent, see separate list Top
Q201 MPSA42 Transistor bipolar signal MPSA42 Top
Q202 MPSA92 Transistor bipolar signal MPSA92 Top
R1 10K.7W1% Resistor Metal Film 10K.7W1% Top
R2 10K.7W1% Resistor Metal Film 10K.7W1% Top
R3 10K.7W1% Resistor Metal Film 10K.7W1% Top
R4 10K.7W1% Resistor Metal Film 10K.7W1% Top
R5 10K.7W1% Resistor Metal Film 10K.7W1% Top
R6 30K.7W1% Resistor Metal Film 30K.7W1% Top
R7 2K.7W1% Resistor Metal Film 2K.7W1% Top
R8 4K7.7W1% Resistor Metal Film 4K7.7W1% Top
