Position Partnumber Description Comment Side
R205 1K53W5% Resistor metal film 1K5 3W 5% Top
R206 10K.7W1% Resistor Metal Film 10K.7W1% Top
R207 100R.7W1% Resistor Metal Film 100R.7W1% Top
R208 5K62.7W1% Resistor Metal Film 5K62.7W1% Top
S5 SPPJ32F29A_ALP Switch inter locking PCB DPDT ALPS SPPJ32F29A Top
U1 MC33078 IC Operational amplifier MC33078 Top
U2 LF353 IC Operational amplifier LF353 Top
U3 VTL5C4 IC photocoupler VTL5C4 Top
U101 MC33078 IC Operational amplifier MC33078 Top
U102 LF353 IC Operational amplifier LF353 Top
U103 VTL5C4 IC photocoupler VTL5C4 Top
U201 NE5532 IC Operational amplifier NE5532 Top
VR1 Variant dependent, see separate list Top
VR101 Variant dependent, see separate list Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position AIDHA-L32 AIDHA-L30 AIDHA-30
C20 1u50V 1u50V -
C21 1u50V 1u50V -
C120 1u50V 1u50V -
C121 1u50V 1u50V -
D16 1N4148 1N4148 -
D17 1N4148 1N4148 -
D18 LYEL2.5X5 LYEL2.5X5 -
D19 LRED2.5X5 LRED2.5X5 -
D20 LGRN2.5X5 LGRN2.5X5 -
D21 LGRN2.5X5 LGRN2.5X5 -
D116 1N4148 1N4148 -
D117 1N4148 1N4148 -
D118 LYEL2.5X5 LYEL2.5X5 -
D119 LRED2.5X5 LRED2.5X5 -
D120 LGRN2.5X5 LGRN2.5X5 -
D121 LGRN2.5X5 LGRN2.5X5 -
P3 TBPI3P90M_SAU - -
P4b PH7P1M PH7P1M -
P103 TBPI3P90M_SAU - -
P104b PH7P1M PH7P1M -
Q9 BC547B BC547B -
Q10 BC557B BC557B -
Q11 BC557B BC557B -
Q109 BC547B BC547B -
Q110 BC557B BC557B -
Q111 BC557B BC557B -
R47 33K.7W1% 33K.7W1% -
R48 8K2.7W1% 8K2.7W1% -
R49 4K32.7W1% 4K32.7W1% -
R50 33K.7W1% 33K.7W1% -
R51 2K2.7W1% 2K2.7W1% -
R52 2K2.7W1% 2K2.7W1% -
R53 68K.7W1% 68K.7W1% -
R54 2K2.7W1% 2K2.7W1% -
