Lab.gruppen iP450 - MR05 Component and Variant Details; MR05 Component List; MR05 Variant Specific Components; MR05 Variant Dependent Component Description

= pÉêîáÅÉ=j~åì~ä=joMR= m~ÖÉ=Q=EQF=
=
`çãéçåÉåí=äáëí=Ñçê=joMR=J=êÉî=MO^=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment Side
C1 u22X22.5 Capacitor 220n X2 metallized propylene 22.5mm Top
C2 2n2Y10 Capacitor 2n2 Y2 metallized paper 10mm Top
C3 2n2Y10 Capacitor 2n2 Y2 metallized paper 10mm Top
C4 100n250VMMK10 Capacitor polyester 100n 250V MMK 10mm Top
C5 100n250VMMK10 Capacitor polyester 100n 250V MMK 10mm Top
D1 KBPC35-06mh Diode bridge KBPC35-06 Top
FU1 T4A250-5x20 Fuse slow blow 4A 250V 5x20mm Top
FU2 T4A250-5x20 Fuse slow blow 4A 250V 5x20mm Top
P2 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P3 FBPC5x209M Fuseblock PCB 5x20mm fuse 9 modules Top
P4 Variant dependent, see separate list Top
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position MR05-MTB MR05-MVS
P4 TBPC3P4M4 -
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
TBPC3P4M4 Terminal block PCB 3pole 4module 4mm2
