Lab.gruppen iP450 - iP450 Component Listings; iP450 Component List; iP450 Variant Specific Components; iP450 Variant Dependent Component Description

= pÉêîáÅÉ=j~åì~ä=ámQRM= m~ÖÉ=P=EQF=
=
`çãéçåÉåí=äáëí=
- Safety critical component. Should only be replaced with the specified type.
Position Partnumber Description Comment
C1 680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm
C2 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm
C101 680p400VK20005%5 Capacitor ceramic 680p 400V K2000 5% 5mm
C102 100n63VMMK5 Capacitor polyester 100n 63V MMK 5mm
K201 K45TOd165h35_LAB Transformer 450W toridial dy165mm h 35mm LAB. Rev01
L201 2x1mH8Ad58h27 Inductor 1mH ironcoil TOROID TI-01027
P1 NL4MP_NEU Connector speakon 4pole NEUTRIK NL4MP
P2 SOIDC5P3.96_AMP Socket IDC 5pole 3.96mm AMP 640427-5
P3 SOIDC6P3.96_AMP Socket IDC 6pole 3.96mm AMP 640427-6
P101 NL4MP_NEU Connector speakon 4pole NEUTRIK NL4MP
P102 SOIDC5P3.96_AMP Socket IDC 5pole 3.96mm AMP 640427-5
P103 SOIDC6P3.96_AMP Socket IDC 6pole 3.96mm AMP 640427-6
P201 Variant dependent, see separate list
S201 RK2-0-20A25x31 Switch Rocker Double Pole Single Trough on - off 20A 25x31mm
s~êá~åí=ëéÉÅáÑáÅ=ÅçãéçåÉåíë=
Position 230V 115V
P201 MLEU3x.752mBLK MLEU3x1.52.5mBLK
aÉëÅêáéíáçå=Ñçê=î~êá~åí=ÇÉéÉåÇÉåí=ÅçãéçåÉåíë=
Partnumber Description
MLEU3x.752mBLK Mains lead EU Plug type CEE7/VII 3x.75mm2 2m Black
MLEU3x1.52.5mBLK Mains lead EU Plug type CEE7/VII 3x1.5mm2 2.5m Black
