SPECIFICATION
Lab.gruppen AB, Gullregnsvägen 16, SE-434 44 Kungsbacka, Sweden.
Tel. +46 300 168 23. Fax +46 300 142 46. www.labgruppen.se
4000
SPEAKER PROTECTION
Each channel is fuse protected on the positive and negative power supply rails. Electronic short-circuit protection with a progressive
characteristic. The output power is turned off at shorted output. The power amplifier can be run into short-circuits for a long time
without damage, and is open circuit and mismatch proof.
DISTORTION
THD 20 Hz-20 kHz and 1 W-1000 W 4 ohms 0.1%
THD at 1kHz and 2000W 4 ohms 0.04%
DIM 30 at 500 W 4 ohms 0.04%
CCIF (13 and 14 kHz) at 500 W 4 ohms 0.04%
SMPTE (60 Hz and 7 kHz) at 500 W 4 ohms 0.04%
POWER BANDWIDTH
3)
5 Hz-20 kHz
Slew rate 20 V/µs
OUTPUT IMPEDANCE
1 kHz 0.06 ohm
HUM AND NOISE below max power
<- 95 dBA
CHANNEL SEPARATION
1 kHz 90 dB
10 kHz 80 dB
PHASE AND DELAY
Deviation from perfect delay 150 Hz–20 kHZ ± 2°
Total delay input to output at 4 ohms 19 µs
INPUTS
Sensitivity, switchable for full output into 4 ohms 92 V 0.775 or 3.2 Vrms
Gain, switchable 41 dB or 29 dB
Impedance 20 kohms, balanced
Common mode rejection at 1 kHz 50 dB
FRONT PANEL
Gain controls
2)
Channel A–B
Output display (2) red + (10) green LED’s Fast peak – slow release
Temp indicator (2) yellow LED’s 80°C at heatzink
VHF indicator (2) yellow LED’s > 10 kHz at full power
On indicator (2) green LED’s DC rail voltage for channel A and B
Ac indicator (1) green LED AC mains present
AFS indicator (1) yellow LED Fuse saver activated
REAR PANEL
Input connectors (2) XLR type 3 pin female (pin 2+), and (2) 1/4” jack
Output connectors (2) Neutric 4-pole speakon connectors (pin 1+ output)
Switches:
Gain 41 dB or 29 dB
Link Tandem mono, channel A and B
Rev B Phase reverse of channel B
Clip limiter A and B On - Off
MLS 0, -2, -4, -5 dB
POWER
Option
Operation voltage 120 V - 270 V AC 65 V-135 V AC
Minimum start voltage 190 V AC 95 V AC
Full output power 180 V -260 V AC 90 V-130 V AC
OVERALL DIMENSIONS
483 (19”) W
mm (inch) x 88 (3.5”) H
x 347 (13,7”) D
WEIGHT
10 kg (22 lbs)
APPROVALS
CE Emission EN 55 103-1, E3
Immunity EN 55 103-2, E3, with, S/N below 1%
at normal operation level
4)
Safety EN 60 065, class I
MAX OUTPUT POWER
1)
EIA at 1 kHz and 1% THD
MLS switch
16 Ω stereo
8 Ω stereo
4 Ω stereo
2 Ω stereo
16 Ω bridged
8 Ω bridged
4 Ω bridged
-5 dB
220 W
430 W
830 W
1660 W
860 W
1660 W
3320 W
-4 dB
260 W
520 W
1000 W
2000 W
1040 W
2000 W
4000 W
-2 dB
410 W
820 W
1600 W
2200 W 3050 W
2)
1640 W
3200 W
4400 W
0 dB Full
650 W
1300 W
2100 W
2400 W, 3200 W
2)
2600 W
4200 W
4800 W
IHF
Peak power
20 ms
650 W
1300 W
2100 W
3200 W
2600 W
4200 W
6400 W
1) Specifications measured with 230 V regulated AC
2) Continuous power, one channel driven or peak power
both channels driven. (Thermal protection may occur
at high continuous power).
Lab.gruppen reserve the right to alter functions or specifications without prior notice.
3) The VHF-protection turns off the channel for
frequencies above 20 kHz at full power.
4) Normal operation level 1/8 of full power or
–9dB below clip point.
